Input Voltage&Frequency
AC 200~240V ,50Hz AC 100~120V ,60Hz
Power
580w
Power Input/Output Connector
SEETRONIC
DMX Singal Interface
3PIN
Control Protocol
DMX512/ DC Electric Control / 15V-24V Fireworks Ignition
Fuel Bottle Capacity
10L
Oil Consumption
60ml/s
Adjustable Height
8-10m
Effects Angles
Any Direction
Maximum Single Continuous Duration
8s
Ignition Mode
High Voltage Electric Ignition
Net Weight
Control Box Net Weight:15kg Flame Head Net Weight: 8.4kg
Gross Weight
NA
Machine Dimensions:
Flame Head Dimensions:229mm *242mm * 367mm Control Box Dimensions:476mm * 332mm * 377mm
Packing Dimensions:
Single Unit Flight Case Dimensions:830mm * 740mm* 720mm
Fuel Oil
ISOPAR
